Díly pro ENGINE CASE
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 77130000244 ENGINE CASE |
30 042 Kč | |
| 6 | 58030021100 OILDRAIN PLUG WITH MAGNET |
196 Kč | |
| 7 | 58038022000 CU-SEAL RING DIN7603-12X18X1,5 |
28 Kč | |
| 8 | 58030010200 SCREW IN NOZZLE M20X1,5 |
166 Kč | |
| 11 | 0025060406 HH COLLAR SCREW M6X40 TX30 |
29 Kč | |
| 12 | 0025060086 HH COLLAR SCREW M6X8 TX30 |
29 Kč | |
| 19 | 58030080000 LOCATING SCREW M8 L=23 |
382 Kč | |
| 20 | 58030081000 CU-SEAL RING 8 X 14 X 3 |
42 Kč | |
| 23 | 77038022000 OIL INTAKEPIPE |
116 Kč | |
| 24 | 59030024000 DOWEL 17 X 19 X 12 |
94 Kč | |
| 26 | 60030064070 OIL JET 70 M6X0,75 WS8 03 |
326 Kč | |
| 27 | 54630027000 DOWEL BUSHING 13,8X11X12 |
143 Kč | |
| 28 | 75030010100 CASE BUSH |
195 Kč | |
| 30 | 59030058000 JET 100 BING(44-031/180) M4 |
60 Kč | |
| 31 | 77130023000 DOWEL 6X8X5,5 |
52 Kč | |
| 34 | 0770120020 O-RING 12,00X2,00 NBR 70 |
17 Kč | |
| 35 | 77038017000 SCREW PLUG |
249 Kč | |
| 36 | 59038015100 OIL SCREEN 11,8x44,5MM |
268 Kč | |
| 37 | 07700900151 O-RING 9X1,5 V80 SH |
21 Kč | |
| 50 | 0025060656 HH COLLAR SCREW M6X65 TX30 |
29 Kč | |
| 51 | 0025060506 HH COLLAR SCREW M6X50 TX30 |
29 Kč | |
| 53 | 0025060306 HH COLLAR SCREW M6X30 TX30 |
29 Kč | |
| 54 | 58038028000 VALVE PISTON D=10MM |
126 Kč | |
| 55 | 58038023300 PRESSURE SPRING L=25MM D=1MM |
66 Kč | |
| 56 | 0908120153 THREADED PLUG DIN 908 M12X1.5 |
87 Kč | |
| 58 | 80030058060 OIL JET \'\'60\'\' M4 |
236 Kč | |
| 59 | 0025060606 HH COLLAR SCREW M6X60 TX30 |
29 Kč | |
| 60 | 77030099101 GASKET SET 05-11 |
5 288 Kč |
