Díly pro CRANKSHAFT, PISTON
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 77130018000 CRANKSHAFT SX-F |
20 054 Kč | |
| 2 | 77030015344 CONNECT. ROD REPAIR SET |
7 890 Kč | |
| 3 | 56030081000 THRUST WASHER 30,5X45X0,10 |
23 Kč | |
| 3 | 56030081100 THRUST WASHER 30,7X47X0,15 |
23 Kč | |
| 3 | 56030081200 THRUST WASHER 30,5X45X0,30 |
29 Kč | |
| 4 | 50330082000 CYL.ROLLER BEAR.NJ206 ET2XCS46 |
1 392 Kč | |
| 6 | 54630029000 HEX.NUT L/SH M18X1,5 |
127 Kč | |
| 7 | 58132072000 LOCK WASHER VSK 18 |
42 Kč | |
| 8 | 0760354774 SHAFT SEAL RING 35X47X7 VITON |
214 Kč | |
| 14 | 77339010100 FLYWHEEL SCREW |
87 Kč | |
| 16 | 6946005 WOODRUFF KEY 5X6,5 HARDED |
33 Kč | |
| 22 | 0888030037 WOODRUFF KEY DIN6888-3X3,7 |
21 Kč | |
| 23 | 77132000022 PRIMARY GEAR 22T. |
1 724 Kč | |
| 33 | 77030033000 PISTON PIN BOLT D=16mm 05 |
560 Kč | |
| 34 | 77030074000 CIRCLIP 05 |
87 Kč | |
| 40 | 77130007100 I PISTON CPL. D=76MM |
7 159 Kč | |
| 40 | 77130007100 II PISTON CPL. D=76MM |
7 159 Kč | |
| 41 | 77130032000 OIL SCRAPER RING |
974 Kč | |
| 42 | 77030030200 COMPRESSION RING |
828 Kč | |
| 43 | 0760142460 RADIAL SHAFT SEAL 14X24X6 B |
77 Kč | |
| 98 | 00050000013 PISTON KIT GR.II EXCF/SXF 06-1 |
7 146 Kč | |
| 98 | 00050000033 PISTON KIT EXC-F/SX-F 06-13 |
7 146 Kč | |
| 99 | 00050002302 CRANKSHAFT REP. KIT 250SX-F/ |
2 229 Kč |
