Díly pro WIRING HARNESS
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 2 | 81211075110 WIRING HARNESS 2010 |
10 795 Kč | |
| 8 | 58411087050 RUBBERCOVER F.LOCKHOLDER |
260 Kč | |
| 9 | 75011088010 FUSE 10A 07 |
69 Kč | |
| 10 | 61111057000 RELAY CM1A-R-12V-H80 07 |
257 Kč | |
| 11 | 69011040000 END PLUG CAN-BUS 08 |
251 Kč | |
| 12 | 000700000BH SPARE CONNECTOR BH 6-PINS |
433 Kč | |
| 19 | 44011076140 CABLE TIE 140/2,5MM BLACK |
10 Kč | |
| 19 | 44011076200 CABLE TIE 200/3,6MM BLACK |
10 Kč | |
| 19 | 44011076305 CABLE TIE 300/4,8MM BLACK |
10 Kč | |
| 20 | 50311050100 BRAKE LIGHT SWITCH FRONT 2002 |
1 187 Kč | |
| 21 | 54211052000 CLAMP RSGU 24/15 |
57 Kč | |
| 22 | 58411096100 DIODE S3H-15 97 |
180 Kč | |
| 23 | 49111425200 BULB 12V 2,3W (W2X4,6D) |
23 Kč | |
| 25 | 81211096000 DUMMY PLUG AN 4-PIN |
135 Kč | |
| 40 | 81214098000 BRACKET F. CONTROL LAMPS |
188 Kč | |
| 41 | 81214083000 INDICATOR LIGHT LED YELLOW FI |
501 Kč | |
| 42 | 81214086000 INDICATOR LIGHT RESERVE |
95 Kč | |
| 43 | 0025060106 HH COLLAR SCREW M6X10 TX30 |
28 Kč |
