Díly pro SHIFTING MECHANISM

Číslo dílu
na schématu
Kód dílu
Název dílu
Cena za kus
vč. DPH
Doporučený
počet
1 54834201000
SHIFT FORK 5./6.G.
1 283 Kč
2 54834202000
SHIFT FORK 2./4.G.
1 283 Kč
3 54834203000
SHIFT FORK 1./3. G.
1 283 Kč
4 0402061480
NEEDLE ROLLER DIN5402 6X14,8
50 Kč
5 54834005133
SHIFT SHAFT ASSY
1 661 Kč
7 58038023200
PRESSURE SPRING 0,9MM
52 Kč
8 61234008044
SLIDING PLATE
150 Kč
9 56534013100
TENSIONING SPRING 0,8MM
44 Kč
10 54634020000
SPRING GUIDE
116 Kč
11 0625069034
BALL BEARING 6903 C4
313 Kč
12 54834212000
SHIFTING DRUM
1 875 Kč
13 0625618050
BALL BEARING 61805 C3
601 Kč
14 54834014000
RETURN SPRING 03
66 Kč
15 54834015133
SHIFT DRUM LOCATING CPL.
768 Kč
16 0012060303
AH SCREW DIN6912 M6X30 8.8
28 Kč
17 0912060083
AH SCREW DIN0912-M 6X 8
18 Kč
18 54634049000
RETAINING PLATE
50 Kč
19 54834019000
SHIFT. RAIL MAIN SHAFT 250/300
206 Kč
20 54834020000
SHIFT. RAIL C. SHAFT 250/300
246 Kč
23 54834023000
LOCKING LEVER SPRING 03
69 Kč
24 50334024144
LOCATING LEVER CPL. 08
238 Kč
25 54634052300
SLEEVE FOR LOCKING LEVER
63 Kč
26 0349000050
WASHER DIN7349-5X15X2
17 Kč
27 0025050206
HH COLLAR SCREW M5X20 TX30
20 Kč
31 54834031000
SHIFT LEVER CPL. 250/300 05
1 370 Kč
32 54634131000
STEP PLATE FOR SHIFT LEVER 250
494 Kč
33 54634031050
BOLT 6X25 FOR SHIFT LEVER
86 Kč
34 54634032100
SHIFTING LEVER SPRING 250
52 Kč
35 54634050000
STOP DISK 14X30X1
29 Kč
36 54632095000
NEEDLE SLEEVE HK 1412 14X20X12
97 Kč
37 0760142460
RADIAL SHAFT SEAL 14X24X6 B
77 Kč
38 50232050001
STEEL WASHER 6,4X17X3
37 Kč
39 50233041000
PAIR OF WASHERS M 6 NORDLOCK
39 Kč
40 59009062016
SPECIAL SCREW M6X16 WS=8 10.9
31 Kč

Další schémata

CARBURETOR CARBURETOR CLUTCH CLUTCH CLUTCH COVER CLUTCH COVER COOLING SYSTEM COOLING SYSTEM CRANKSHAFT, PISTON CRANKSHAFT, PISTON CYLINDER, CYLINDER HEAD CYLINDER, CYLINDER HEAD ELECTRIC STARTER ELECTRIC STARTER ENGINE CASE ENGINE CASE EXHAUST CONTROL EXHAUST CONTROL IGNITION SYSTEM IGNITION SYSTEM KICK STARTER KICK STARTER REED VALVE CASE REED VALVE CASE SHIFTING MECHANISM SHIFTING MECHANISM TRANSMISSION I - MAIN SHAFT TRANSMISSION I - MAIN SHAFT TRANSMISSION II - COUNTERSHAFT TRANSMISSION II - COUNTERSHAFT

SHIFTING MECHANISM

Zvětšit schéma SHIFTING MECHANISM
SHIFTING MECHANISM
