Díly pro CRANKSHAFT, PISTON
| Číslo dílu na schématu | Kód dílu Název dílu | Cena za kus vč. DPH | Doporučený počet |
|---|---|---|---|
| 1 | 80530018100 CRANKSHAFT CPL. |
20 054 Kč | |
| 2 | 78330015044 CON ROD REP.-KIT 400 09 |
8 317 Kč | |
| 3 | 78330007100 I PISTON CPL. |
7 275 Kč | |
| 3 | 78330007100 II PISTON CPL. |
7 275 Kč | |
| 4 | 78030030100 COMPRESSION RING |
674 Kč | |
| 5 | 78030032200 OIL SCRAPER PISTON RING |
674 Kč | |
| 6 | 78030033000 PISTON PIN 08 |
1 163 Kč | |
| 7 | 77330074000 CIRCLIP |
360 Kč | |
| 8 | 79430082000 CYLINDER ROLLER BEARING NJ207 |
1 225 Kč | |
| 9 | 0760354774 SHAFT SEAL RING 35X47X7 VITON |
214 Kč | |
| 10 | 56530081000 SHIM WASHER 36X48X0,10 |
28 Kč | |
| 10 | 56530081100 SHIM WASHER 36X48X0,15 |
33 Kč | |
| 10 | 56530081200 SHIM WASHER 36X48X0,20 STEEL |
39 Kč | |
| 10 | 56530081300 SHIM WASHER 36X48X0,30 |
26 Kč | |
| 13 | 78030029200 NUT PRIMARY WHEEL M20X1,5 |
126 Kč | |
| 14 | 78032000333 PRIMARY WHEEL |
3 153 Kč | |
| 15 | 78036014200 TIMING GEAR 18T. |
558 Kč | |
| 16 | 0888030037 WOODRUFF KEY DIN6888-3X3,7 |
21 Kč | |
| 17 | 0760142460 RADIAL SHAFT SEAL 14X24X6 B |
77 Kč | |
| 99 | 00060000032 PISTON KIT GR. I FE 390 10-12 |
7 146 Kč | |
| 99 | 00060000033 PISTON KIT GR. II FE 390 10-12 |
7 146 Kč |
